CHARACTERISTICS
Manufactured from close grained high tensile seasoned cast iron. Vises has one fixed horizontal axis which allows the work piece to be rotated at any angle along it. Fully graduated 360Â° swivel base allows complete rotation along the vertical axis. The third angular slide with moving axis allows for any setting in 3D plane. Jaws are fully hardened and ground with in a parallelism of 0.0012" (30 microns). The hardness of jaws is 55Â±5 HRC.

Ordering No.	Length		Width		Height		Jaw Width		Jaw Opening		Jaw Depth		Base Length		Net Weight Kgs.
	Inch	mm	Inch	mm	Inch	mm	Inch	mm	Inch	mm	Inch	mm	Inch	mm
110060	6.3/4	170	3.3/4	95	5.1/4	130	2	50	2	50	1	25	5.3/8	135	4.000
110061	10	255	5.5/8	145	7.3/16	185	3	75	3	77	1.1/4	30	8	200	11.500
110062	11.5/8	295	6.1/2	165	8.1/16	205	4	100	4	100	1.1/2	40	8.7/8	225	19.000
